Orchard Core Shapes: Demystifying the View Data Model

Orchard Core doesn't render HTML directly. Instead, it renders Shapes — objects that represent what to render and carry all the data and metadata needed to produce HTML. Understanding shapes is fundamental to customising and theming Orchard Core applications.

What Is a Shape?

A shape is an object implementing the IShape interface. It is a dynamic data model containing:

• Data — values that will be rendered by ASP.NET views
• Metadata — instructions on how to render (template name, alternates, placement, etc.)

Benefits of the Shape System

• No view name is hard-coded — the view name is derived from the shape type
• Priority-based view resolution via Alternates (multiple templates can match the same shape, resolved in priority order)
• Theming — user-defined templates (views) override default ones without modifying core
• Dynamic caching
• Wrapping and placement (zones, ordering)
• Multiple data sources (database, files, code)
• Event-driven rendering pipeline

Creating and Rendering Shapes

The basic flow for creating and rendering a shape programmatically:

// 1. Create a shape by shape factory
var factory = context.RequestServices.GetRequiredService<IShapeFactory>();
var shape = await factory.CreateAsync("Car");

// 2. Render to HTML via display helper
var displayHelper = context.RequestServices.GetRequiredService<IDisplayHelper>();
var htmlContent = await displayHelper.ShapeExecuteAsync(shape);

// 3. Create a view matching the shape name: Car.cshtml

// 4. Write HTML to response
await using var sw = new StreamWriter(context.Response.Body);
htmlContent.WriteTo(sw, HtmlEncoder.Default);

Code for this pattern is available on GitHub: Test_Shape_With_Razor_View

Rendering Shapes with Liquid Templates

Liquid is a secure, flexible templating language ideal for dynamic content generation in Orchard Core.

To use Liquid templates instead of Razor views, add the OrchardCore.DisplayManagement.Liquid package and register AddLiquidViews() in Program.cs. Orchard Core will resolve a Car.liquid template for a shape of type "Car".

Adding Data to Shapes

The IShape interface exposes a Properties dictionary (IDictionary) where you store data accessible in templates via the Model object:

shape.Properties["Brand"] = "Renault";
shape.Properties["Color"] = "Red";

In the template, data is accessed as Model.Brand (not Model.Properties["Brand"]) because the DynamicObject-based Compose class implements TryGetMember, enabling direct property access.

Code: Test_ShapeData_With_Liquid_Template

Strongly Typed Shapes

For better performance and IDE support, use the generic CreateAsync<T> overload to bind a POCO class to the shape:

public class Car
{
    public string? Brand { get; set; }
    public string? Color { get; set; }
}

var shape = await factory.CreateAsync<Car>("Car", c =>
{
    c.Brand = "Renault";
    c.Color = "Red";
});

In the view, type the model directly:

@using OrchardCore.DisplayManagement;
@model Car

This is a car @Model.Brand with @Model.Color color

Adding Metadata to Shapes

IShape metadata controls how the shape is wrapped in HTML. Key properties:

shape.Id = "my-renault";
shape.TagName = "h3";
shape.Classes.Add("car");
shape.Classes.Add("brand-renault");
shape.Attributes.Add("data-brand", "renault");

Render the metadata in a Razor template using the tag builder helper:

@using OrchardCore.DisplayManagement;
@model Car

@{
    var shape = Model as IShape;
    var tagBuilder = shape.GetTagBuilder();
}

@tagBuilder.RenderStartTag()
This is a car @Model.Brand with @Model.Color
@tagBuilder.RenderEndTag()

The resulting HTML:

The HTML source shows the metadata-driven output:

Code: Test_Shape_With_Metadata

References

• Orchard Harvest 2024: Demystifying Shapes, Part 1
